Used mounted concrete pump truck for sale

FOB Reference Price:Get Latest Price
$158,000.00 - $256,000.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Dimension(L*W*H):
According to the model
Weight:
Depend on the model
Condition:
New
Place of Origin:
China
Brand Name:
Others
Model Number:
ZLJ5339THB 49X-6RZ
Certification:
ISO9001,CE
Power Type:
Electric
Power(W):
300/1800Kw(r/min)
Max. Concrete Output:
170/120m3/h
Max. Concrete Pressure:
8.3/12MPa
Delivery Cylinder:
260mm
Stroke Length:
2100mm
Hopper Capacity:
600L
Filling height:
1540mm
Max. Reach Vertical:
49m
Max. Reach Horizontal:
45m
Max. Reach Depth:
34.1m
Min. Unfolding Height:
3m
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1year
Supply Ability
Supply Ability:
30 Set/Sets per Year According to customer demand
Packaging & Delivery
Packaging Details
Nude without packing and some parts and model into container.
Port
Every port in China
Lead Time :
20 days after receiving deposit

Used mounted concrete pump truck for sale

Product Description

 Compact in design, 49m pump mounted on a 4-axle truck.
• Efficient pump unit, ideal for long time use.
• Agile placing boom with 6 arms with unfolding height 9.5m only,which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor, itmonitors the pump intelligently on working data management,real-time diagnostics, alarm logging, and service interval notice.
• Rich in configurations and high quality components.
• Boom with damping technology.
• Stabilization control on boom.
• Multilingual man-machine interface system.
• PWM+CAN dual communication mode remote control

concrete  pump trucks1.jpg

Technical parameters



Truck mounted concrete pump 48m
Unit
Parameters
HDT5380THB-48/5
HDT5401THB-48/5
Main technical parameters in working condition
Theoretical Productivity
m3/h
125
Pumping Capacity Index
MPa.* m3/h
586
Max. Concrete Pressure
Mpa
8.5
Hopper Capacity
L
700
Feeding Height
mm
1400
Model of Distributing Valve

S pipe valve
Distance between Front Landing Legs
mm
9780
Distance between Rear Landing Legs
mm
9860
Close-control Distance
m
33
Remote-control Distance
m
200
Main technical parameters in
driving condition
Max. Traveling Speed
km/h
89/85
Min. Turning Radius
mm
11900/12100
Chassis Model

ZZ5437S4667C
CYH51Y
Wheel Base between the Third and the Fourth Axle
mm
1310/1350
Front Tread
mm
2065/2022
Overall Dimension
(length×width×height)
mm
13300*2500*4000
Full-load Total Weight
kg
38000/40000



concrete pump trucks3.jpg
